Qianli CX3 CX4 CX60 CMOS industrial Camera
Color:CX3 CMOS
Quantity:
Qianli CX3 CX4 CX6 CMOS Industrial Camera 1080P 4800W Image Sensor
Qianli MEGA-IDEA CMOS industrial camera 1080P 60FPS 4800W image sensor. Mega-idea CX3 CX4 CMOS industrial camera with HDMI/USB Output for industrial microscopes. Mega-idea CX3-CMOS industrial microscope camera C/CS mount. Mega-idea CX4-CMOS industrial microscope camera C mount. One key exposure White balance Adjustable Remote Control Microscope Camera, Digital Video Recorder for Microscope Medical Micrographics Machine Vision.
Mage-Idea CX60 CMOS 4K Ultra HD Industrial Microscope Camera for PCB Soldering Repair. Mega-idea CX60 CMOS 4K industrial camera With Standard C/cS height adapter ring Work trinocular mircoscopes.
Specifications:
Sensors: 1/2.33 inch CMOS sensor
Pixel size: 1.335 um x 1.335 um
HDMI output: 1920 * 1080 60fps
USB output: 1920 * 1080/30 1280 * 720/30 640 * 480/30 320 * 240/30 (MJPG)
Lens Interface: C/CS mount(CX3), C mount(CX4).
Exposure: Auto / Manual / One key exposure
Exposure compensation: support
White balance: automatic / manual, RGB adjustable
Storage: Maximum support 64GB
Input voltage: DC 5V-12V
Scribe line support 8 lines, color, thickness and position adjustable
Centerline: support
Image Pixel: 48M Pixel
Language: English / Chinese
Remote control: support remote control
MEGA-IDEA CX60 CMOS 4K Industrial Microscope Camera Specification:
Resolution: HDMI: 3840*2160@30FPS; 1920*1080@60FPS; Type-C: 3840*2160/2560*1440/1920*1080/1280*720/640*480/424*240/320*240(MJPG).
Input power: DC 5V.
Operation method: Mouse/remote/keys/PC software.
CMOS sensor: Sony 1/2.8 inch 8M pixel.
Pixel size: 1.45μm*1.45μm.
Hardware Interface: Type-C*1,HDM*1,TF*1.
Expansion Interface: 1/4 inch bracket interface*1.
Indicator: Orange color power light.
Lens mount: C/CS standard lens mount.
Storage: TF card/computer software.
Key: Function key*6.
White balance: Auto/Manu, support R/G/B adjust.
Expose: Auto/Manu exposure.
Menu language: Chinese/English/Traditional Chinese.
Photoshoot/video record: Auto/Manu name the file and the save path.
Digital zoom in: 5 times digital zoom in.
Features:
1. Delivering high-definition video up to 60fps over HDMI, and can capture video and still images, and includes limited processing features.
2. With the included monitor, 1080p live video can be viewed at a super-smooth 60fps. high quality, high resolution and clear images.
3. The included USB mouse allows you to make adjustments in the internal software for settings such as white-balance and exposure, and control recording functions.
4. As an alternative solution, the camera can be connected to a PC via USB. View a live feed on the monitor while simultaneously viewing and recording 30fps video or stills on your PC.
5. The industry-standard C-mount design allows this camera to be connected directly to C-mount photo-ports, or used in conjunction with an array of optional lenses and adapters to mount to virtually any popular microscope line.
6. Support HDMI USB two output, high work efficiency, high video resolution. Sharpness, saturation, contrast, horizontal and vertical mirroring are manually adjustment.
7. Small size, light weight and easy to carry. It supports pictures and videos playback, supports English/Simplified Chinese language.
Application: Electronics, Medicine, Science, Jewelry, Mobile Phone Repair, Education, ect.
